PRODUCT DESCRIPTION
| ITEM | Voltage (v) |
Best input Voltage (DC) |
Power (w) |
Max. Flow (m³/h) |
Max. Head (m) |
Outlet (in) |
Open circuit voltage (VOC) |
Solar Panels Suggestion | |||
| Voltage (V) |
Power (w) |
Quantity (pcs) |
Connection | ||||||||
| 3WSP4.5-35-24-300 | 24 | 30-48V | 300 | 4.5 | 35 | 1.25"-1" | <50V | 36 | 250 | 2 |  |
| 3WSP4.5-50-48-400 | 48 | 60-90V | 400 | 4.5 | 50 | 1.25"-1" | <100V | 36 | 300 | 2 |  |
| 3DCSP4.5-80-48-600 | 48 | 60-90V | 600 | 4.5 | 80 | 1.25"-1" | <100V | 36 | 250 | 4 |  |
| 3WSP5-97-72-750 | 72 | 90-120V | 750 | 5 | 97 | 1.25"-1" | <150V | 36 | 330 | 3 |  |
| 3WSP5-130-72-1100 | 72 | 90-120V | 1100 | 5 | 130 | 1.25"-1" | <150V | 36 | 300 | 6 |  |
| 3WSP5-142-110-1100 | 110 | 110-150V | 1100 | 5 | 142 | 1.25"-1" | <200V | 36 | 300 | 6 |  |
| 3WSP5-160-110-1500 | 110 | 110-150V | 1500 | 5 | 160 | 1.25"-1" | <200V | 36 | 300 | 8 |  |
| ITEM | Motor Power | Capacity and head | ||||||||
| L/min | 0 | 17 | 33 | 42 | 50 | 58 | 67 | 75 | 83 | |
| m³/h | 0 | 1 | 2 | 2.5 | 3 | 3.5 | 4 | 4.5 | 5 | |
| 3WSP4.5-35-24-300 | Head (m) |
35 | 28 | 22 | 18 | 16 | 13 | 11 | 8 | / |
| 3WSP4.5-50-48-400 | 50 | 41 | 32 | 27 | 23 | 20 | 16 | 12 | / | |
| 3WSP4.5-80-48-600 | 80 | 68 | 53 | 44 | 37 | 32 | 27 | 19 | 1 | |
| 3WSP5-97-72-750 | 97 | 85 | 76 | 63 | 54 | 45 | 38 | 25 | 14 | |
| 3WSP5-130-72-1100 | 130 | 102 | 79 | 66 | 56 | 48 | 40 | 28 | 18 | |
| 3WSP5-142-110-1100 | 142 | 110 | 85 | 77 | 63 | 52 | 43 | 35 | 25 | |
| 3WSP5-160-110-1500 | 160 | 125 | 96 | 80 | 70 | 59 | 51 | 42 | 31 | |
Keywords:
Since 2012
Taizhou Werto Mechanical & Electrical Co., Ltd.
Taizhou Werto Mechanical & Electrical Co., Ltd. is a company which specialized in water pumps and electric motors for the R&D,manufacture and sales.Our company was founded in 2012 and located in China ‘s pump town,Wenling,Zhejiang,China. We are one of modern enterprises which acquire the core technology of water pumps and electric motors,we implement modernization management ,all our products are in conformity with ISO9001 international standard. Besides we have all necessary automation machineries and equipments to keep high productivity and stable quality.
Your contact details
Note: Please leave your contact information and our professionals will contact you as soon as possible!
3” 3WSP4.5 DC Brushless SS impeller Deep Well Solar Pump
Summary:
Solar Energy Pumps Work
First step:The sun shines on the surface of the solar panels meanwhile the movement of electrons generates DC power will be transferred through attached wires to the pump controller.
Second step:The pump controller as the brains of the system and with sophisticated technology and sensor inputs,it starts the submersible motor and drives the pump to lift water against gravity to the surface.
